Vertical Hydraulic Metal Briquetter

Vertical Hydraulic Metal Briquetter

1. Pressing force of the metal briquetter is up to 630T.
2. Ferrous powder, copper powder,aluminum power are applicable for the metal briquetter.
3. Metal feeding hopper size could be customized as requirement.
Send Inquiry
Description

Introduction

Our Vertical Hydraulic Metal Briquetter have good rigidity and stability, beautiful shape, easy operation and maintenance, and much higher safety performance than the rest of the products. In addition, our pushing cylinder and pushing head are connected with spherical structure, which has excellent reliability and makes the service life of our oil seal longer. Finally, our products have reasonable price and good quality, which are popular among customers.


Features:

The hydraulic cylinders of our products all adopt solid fire plug rod, and we add cutting knives around the hydraulic cover, which can easily cut various materials and save time and effort. Secondly, the air filter in our Vertical Hydraulic Metal Briquetter can absorb the dirty air and ash layer in the hydraulic oil to protect the service life of the cylinder more effectively. The biggest advantage of our products is that they can compress various materials, no matter what kind of materials can be easily dealt with.


Technical Parameters:

Name

Vertical Hydraulic Metal Briquetter

Model

BM-400

Main cylinder pressure

4000KN

Side cylinder pressure

120KN

Motor power

30/37KW

Processing capacity

1800-2600KG/H

Briquette size

Φ120*70-130


BM-400 Vertical Hydraulic Metal Briquetter -
