Introduction:
As a professional manufacturer of recycling equipment, we have introduced this Enamel Copper Wire Grinding Machine to meet the needs of experienced metal recycling plants. It is well constructed, easy to transport and store, has a small floor area, can be used in small work rooms and boasts high recycling efficiency. In addition, it is suitable for all standard industrial and domestic scrap copper and aluminium wires, especially motor cables, enamelled wires, automotive cable harnesses and other special wires.
Features:
1. Our Enamel Copper Wire Grinding Machines use PLC intelligent operation system, you can start and shut down the machine with one key, convenient and easy to operate.
2. It comes with easy to clean grinding discs and hardened cutting blades that do not require much maintenance or care, and the barn door is locked when working to avoid dust spillage.
3. We have also designed heat sinks around the machine to help dissipate heat quickly when operating at high speeds and to extend the life of the machine,so the machine's life is also extended.
Specification:
Name | Enamel Copper Wire Grinding Machine |
Model | WG-600C |
Applicable wire diameter range | 1-30mm |
Processing capacity | 300-320kg/h |
Power | 47KW |
Voltage | as required(3 phases) |
Dimension | 4.3*1.95*3.2m |
Weight | 3200KG |
Working procedure:
Cable feeding-cable granulating- air separating-second vibration separating.
1. With a conveyor between the cable crusher part and cable separator, it makes the crushed cable go to the vibrating table fastly.
2. Cable separator includes air separating and vibration separating table. The bottom fan of the granulator machine is controlled by a frequency converter.
