Working principle of copper and aluminum separator: Use a dry crusher, strong magnetic roller sorting, and airflow sorting machine to crush and sort waste heat sinks. The whole process is carried out under negative pressure.
The copper wire separator first manually feeds the hard materials such as large pieces of iron or screws with oversized diameters, shaft materials, etc. to take out in advance. Then enter the crushing host for coarse crushing, and then enter the secondary crushing host for fine crushing.
Let the iron sheet, copper, etc. fall off, and then separate the aluminum, iron, and copper with the strong magnetic roller and the air separator. The pulse dust removal system is configured in the crushing and sorting process to effectively solve the dust emission.
1. Manually put the waste materials into the separation crusher. The crusher squeezes and tears the water tank and breaks it into strip radiators with a width of 5 cm and uneven length. The crushed materials are transported by the first discharge conveyor to the second pulverizer.
2. For the second crushing, a heavy-duty hammer mill is used to crush the water tank into flakes. Under the belt magnetic separator on the discharge conveyor, the iron in the material is separated by the magnetic separator, and the remaining copper is separated.
Airflow sorting is carried out in the winnowing machine with an aluminum conveyor. The sorting machine has 2 outlets, one is for heavier mixed materials (copper and a small amount of aluminum), and the other is for lighter pure aluminum.
3. The material is transported by the conveyor to the specific gravity sorter for fine sorting, and the remaining copper and aluminum are sorted out.
What are the benefits of a dry copper wire separator:
1. The dry copper wire separator is based on market feedback due to its high degree of automation, energy saving, and large output
2. With the Copper Cable Separator, you don’t have to worry about the whereabouts of waste wires and cables. This equipment can crush unnecessary materials together, which improves production efficiency and also contributes to the recycling of waste wires and cables, allowing resources to create value in use.
3. Copper Cable Separator equipment is clean and environmentally friendly for the recycling of waste wires and cables. It can fully recycle the plastic and metal copper in waste wires and cables without any environmental pollution.
It mainly adopts the method of mechanical physical crushing and then separates copper and plastic from the pulverized metal-plastic mixture through a specific gravity separator.
4. Platform combined equipment, all parts are directly fixed on the platform, easy to move and transport and the user can work and produce after returning home without installation.
5. The Small Scale Copper Cable Separator adopts a fully automatic power distribution cabinet, with intelligent operation and an automatic alarm. Only one person can complete the operation, saving worry, time, and effort; high production and energy saving, and the sorting rate can reach 97%-99%.
Now the dry copper wire separator technology is very mature and has been exported to other countries many times, which not only meets the good demand of investors for dry copper wire separators but also opens up new markets and new fields for environmental protection equipment.
It is a new weapon for the environmental protection industry, which is of great significance to social benefits, environmental protection benefits, and personal benefits.
The dry copper wire separator is an all-in-one device, which can automatically complete the automatic separation of the entire waste miscellaneous wires and wires, with a small footprint, high output, and high separation purity.
